- Capacity: 72L, 138L, 270L
- Circulation Mode: Natural convection
- Temperature Range: 50-250°C
- Equipped with parameter memory function
- PID temperature controller with LED digital display for precise temperature control
Infrared Fast Heating Drying Oven, DON-IF-H Series
Descripción
Application
It adopts efficient and low consumption far-infrared heating technology, which has good effects on rapid drying work and test samples. It can be widely used in industrial, agricultural, medical, scientific research projects and laboratories.
Features
- Outer casing material: Cold-rolled steel plate with powder coating; Inner casing material: SUS stainless steel plate.
- Infrared thermal radiation heating method, efficient and rapid.
- PID temperature controller with LED digitaldisplay for precise temperature control.
- Supports continuous or timed operation: 0~9999min.
- Equipped with a parameter memory function, automatically resumingoperation upon power restoration.
- There is no glass inner door, and the outer door has an observation window.
- Top-mounted adjustable air outlet.
- The inner chamber adopts a rounded arc structure design for easy cleaning.
- Removable shelves with adjustable spacing.
- (Optional) Independent external temperature protection device.
- (Optional) LCD screen temperature controller.
- (Optional) LCD temperature controller + RS485 communication interface.
- (Optional) LCD screen temperature controller+ micro dot-matrix printer.
- (Optional) RS485 to USB adapter.
Specification
| Model | DON-IF72H | DON-IF138H | DON-IF270H | |||
| Capacity (L) | 72 | 138 | 270 | |||
| Circulation Mode | Natural convection | |||||
| Dimensions
(W*D*H) |
Internal (mm) | 400*400*450 | 500*500*550 | 600*600*750 | ||
| External (mm) | 730*565*702 | 830*665*772 | 930*765*972 | |||
| Temperature Range (°C) | 50-250 | |||||
| Temperature Uniformity (°C) | ≤ Max. Temp. ±3.5 | |||||
| Temperature Fluctuation (°C) | ±1 | |||||
| Shelves | 2 | 3 | 3 | |||
| Electricity | Voltage / Frequency | 1Ø, 220V/50Hz | ||||
| Consumption (W) | 1200 | 1600 | 1900 | |||
| Alarm Type | Over temperature alarm, temperature probe damage alarm | |||||
| Note: External depth (D) includes 6.5cm accessories; height (H) includes 1.2cm accessories | ||||||
